Description

Advantage:

• Small size, simple structure, easy operation;
• External DC24V input, up to four channels of current output;
• The current of each channel can be adjusted manually or by RS232 communication network, and the dynamic response speed is fast;
• High-precision constant current output, non-interference with each other, to ensure constant brightness when the light source is working;
• Up to 10,000 levels of brightness control;
• High current output with fan cooling, longer product life;
• With trigger function, the trigger time can be set by its own controller or an external trigger.

Electrical parameters:

• Number of channels: 4
• External input voltage: DC-24V
• Output voltage: DC-24V
• Output current: 0.1~999.9mA*4
• Output current error: +-0.3mA
• Adjustment accuracy: 0.1mA
• Display accuracy: 0.1mA
• Output power: 24W*4

Dimming parameters:

• Dimming mode: manual control or RS232 setting
• Manual adjustment: adjust accordingly through the buttons on the controller panel

Environmental parameters:

• Working temperature: 0 - 40°C, humidity 20- 85%
• Storage environment: 0 - 60°C, humidity 20- 85%

Mechanical parameters:

• Shell material: aluminum alloy
• Appearance color: anodized black
• Dimensions: 150*97.5*41MM
• Weight: 0.6KG

If you have any other special needs, please contact us so that we can serve you 1 to 1 with excellent professional knowledge and high-quality service attitude which will always fulfill customer's demand.
